Introduction

According to the requirement of modern industrial product design, our escalator control cabinet applies the golden section design method for the section size of the cabinet and each part, which makes the cabinet be elegant and new appearance. In view of the heat radiating problem, the heat radiating holes on the upper and below part of the cabinet has been designed. When the electrical components generate heat, the heat will be exhausted through the upper holes as the heat generates and the cold wind will consistently enter into the cabinet through the below holes, which makes the sealed cabinet become an air duct to realize the heat radiating purpose.

Our escalator control cabinet with sealing design is approved by third testing party and labeled as security level of IP54, which can be used in different working conditions. The cabinet door and operating handle of breaker or isolating switch is designed with a mechanical interlock, the handle can be opened only when the door is in the subsection position which improves the safety of operator.

KYM08E301 embedded automatic escalator control board
KYM08E301 embedded automatic escalator control board is on the basis of ARM 32 microprocessor which is an independently developed product of high technology and delivers a stable quality performance and high capacity of anti interference. This product has the following characteristics.

Escalator programmable electronic safety related systems (PESSRAE)
The systems meet with European standard: EN115-1:2008+A1:2010 and IEC61508 on the corresponding requirement of the programmable electronic safety related systems.

The system uses the security controller: G9SP, the controller itself is certified by TUV safety protection comes to SIL3 level.
